  • Oil-Less Piston Air Compressors.
  • Rated for 100% Continuous Duty Cycle.
  • Unique design allowing for ease of maintenance.
  • TEFC high efficiency electric motors.
  • Direct drive transmission eliminating the need for belts.
Typical Lead time is 1-2 weeks, but varies based on demand.
Unit of Measure

Specifications

Brands

 N/A GTek Automation

Certifications

 N/A American Society of Mechanical Engineers (ASME) c CSA® us European Conformity (CE) International Organization for Standardization (ISO 13485-2008) International Organization for Standardization (ISO 9001-2008) Restriction of Hazardous Substances (RoHS) Compliant

LTL Freight Quoted Separately

 N/A Price Before LTL Freight Please submit quote and we will get back to you on shipping cost.

Technical Data

Power

 N/A 5.5 hp

Output Free Air

 N/A 27.5 ft³/min780 L/min

Maximum Pressure

 N/A 145 psi10 bar

Maximum Current at 460 Volt (V) Voltage and 60 Hertz (Hz) Frequency

 N/A 8.5 A

Noise Level

 N/A 72 dBA

Tank Size

 N/A 52 gal200 L

Weight

 N/A 260 lb

Voltage

 N/A 208 V240 V460 V

Phase

 N/A 3

Frequency

 N/A 60 Hz

Dimensions

Height

 N/A 57 in

Width

 N/A 21 in

Length

 N/A 47 in

Packed Dimensions and Weight

Packed Height

 N/A 62 in

Packed Width

 N/A 26 in

Packed Length

 N/A 58 in

Packed Weight

 N/A 300 lb

Additional Information

Additional Information

 N/A
  • Integrated aftercooler.
  • Each compressor has individual air intake filter.
  • 52 Gallon ASME air receiver that is Corrosion Resistant.
  • Long Service Life backed by a 12 month warranty and dedicated tech support.
