- Completely Oil-Less Quiet Operation.
- Internally Powder Coated Air Tank.
- Pressure Switch Allowing for Automatic Start & Stop.
- Outlet Pressure Regulator.
- Silencing Enclosure with Casters.
Unit of Measure
Specifications
|
Technical Data
|
Dimensions
|
Packed Dimensions and Weight
|
Additional Information
Specifications
Brands |
N/A GTek Automation |
Certifications |
N/A American Society of Mechanical Engineers (ASME) c CSA® us European Conformity (CE) International Organization for Standardization (ISO 13485-2008) International Organization for Standardization (ISO 9001-2008) Restriction of Hazardous Substances (RoHS) Compliant |
Technical Data
Power |
N/A 0.75 hp |
Output Free Air |
N/A 3.71 ft³/min105 L/min |
Maximum Pressure |
N/A 116 psi8 bar |
Maximum Current at 100 Volt (V) Voltage and 50/60 Hertz (Hz) Frequency |
N/A 9.8 A |
Maximum Current at 115 Volt (V) Voltage and 60 Hertz (Hz) Frequency |
N/A 7.8 A |
Maximum Current at 220 Volt (V) Voltage and 60 Hertz (Hz) Frequency |
N/A 4.8 A |
Noise Level |
N/A 57 dBA |
Tank Size |
N/A 1.57 gal6 L |
Weight |
N/A 65 lb |
Voltage |
N/A 115 V |
Frequency |
N/A 60 Hz |
